  Silicone + Rubber NS--N x LEDs

  || 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 000

  N

  tondo

  NS--N x LEDs

  2008





  Type of cable insulation:	Silicone + Rubber for LEDs
  Working temperature of the sheath:	T60°C (T90°C)
  Working temperature inner cores:	T180°C
  Type of strand:	Copper red flexible
  Working voltage:	60V
  Cable for Outdoor use (usable also for permanent immersion in water).



  Code	Sections / AWG:	Colours of the cores	Diameters / Dimensions (mm):
  NS20N	2 x 0.50 mm²	RN	5.9	::NS20N::	NS20N|5.9||2|RN|N
  NSQ0N	4 x 0.50 mm²	RNLV	6.9	::NSQ0N::	NSQ0N|6.9||4|RNLV|N
  NSS0N	6 x 0.50 mm²	R R/N L L/N V V/N	7.9	::NSS0N::	NSS0N|7.9||6|R R/N L L/N V V/N|N

  Available colours:

  • N - Black

  Colours of the cores

  R = Red
  N = Black
  L = Blue
  V = Green
  =
  / =
