  FEP + Silicone - Transparent (Clear) H0--T

  || 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 000

  T

  tondo

  sn

  H0--T

  1993





  Type of cable insulation:	FEP + Silicone - Transparent (Clear) multi-conductor 250V
  Working temperature of the sheath:	T180°C
  Working temperature inner cores:	T180°C
  Type of strand:	Copper tin-plated flexible
  Working voltage:	450/750V
  Inner cores approval:	IMQ



  Code	Sections / AWG:	Colours of the cores	Diameters / Dimensions (mm):
  H027T	2 x 0.75 mm²	tt	4.7	::H027T::	H027T|4.7||2|tt|T
  H021T	2 x 1.00 mm²	tt	5.1	::H021T::	H021T|5.1||2|tt|T
  H025T	2 x 1.50 mm²	tt	5.9	::H025T::	H025T|5.9||2|tt|T
  H037T	3 x 0.75 mm²	ttg	5.2	::H037T::	H037T|5.2||3|ttg|T
  H031T	3 x 1.00 mm²	ttg	5.6	::H031T::	H031T|5.6||3|ttg|T
  H035T	3 x 1.50 mm²	ttg	6.2	::H035T::	H035T|6.2||3|ttg|T

  Available colours:

  • T - Transparent (Clear)

  Colours of the cores

  t =
  g = Transparent + yellow/green
